Примечания по использованию:
Перед работой проверьте водяной насос, струйный шланг, сопло, клапаны и предохранительные устройства. Выберите подходящее давление в зависимости от диаметра, материала и состояния трубы. Никогда не эксплуатируйте насос без достаточного количества воды. Держите персонал подальше от шлангов и насадок, находящихся под давлением, и полностью сбрасывайте давление в системе перед заменой аксессуаров или выполнением технического обслуживания.
| Maximum Load Capacity： | 32T | Type： | Semi-trailer |
| Material： | Steel | Compatible Vehicles: | Truck trailer |
| Brand: | KM | Country of Origin: | Jiangsu, China |
| Dimensions: | 12000*2500*3800mm | Product Name: | Vacuum tanker trailer |
| Axle: | FUWA or as per customer's requirement | Suspension: | ONE set of three axles (Mechanical Suspension) |
| King pin: | 90#/50# | Landing Gear: | FUWA Standard 28Ton |
| Tire: | 12pcs 11.00r22.5 | Vacuum Pump: | Liquid Ring Pump |
| Diesel Engine: | Weihai or Dongfeng Cummins | Function: | Suction and transport waste oil or sewage water |
| Color: | Customers Optional | ||
| No. | Main Components | Detailed Description |
| 1 | Vacuum refueling machine: | Design pressure +/- 2 bar, can be made of carbon steel, stainless steel or aluminum, 6 mm thick tank shell, tank volume 20 to 40 CBM, 6 hoses and 6 drain ports, 2 450 mm diameter manholes on top, on the ladder in front of the tank. |
| 2 | Vacuum System: | Rotary pump, 500 to 3000 CBM/H, located in front of or below the fuel tank; diesel engine brand: KOFO or Commins. |
| 3 | Operating System: | 3x13ton Fuwa axles, dual wheels, 12 x 11.00r22.5 tires with 12 rims, commodity suspension, 3.5" kingpin, FUWA brand landing gear. |
| 4 | Braking System: | Dual-line air brake |
| 5 | Electronic Systems | A complete 24V system with waterproof installation, featuring rear lighting, stop, parking, turn signals, fog lights, reversing lights, and side lights. |
| 6 | Painting | All steel parts are sandblasted with steel sand before painting. Two primer coats and two topcoat coats are applied; colors will be customized according to customer requirements. |
